JVC DLA N5 4K UHD Projector
JVC’s DLA N5 4K UHD Projector is available to pre-order now, expected late December 2018
JVC DLA N5 4K-resolution D-ILA Projector
High-quality, Clear Picture with Brightness
Maximum brightness of 2,200 lm*2 can be achieved by combining a 265 W ultra high-pressure mercury lamp and a highly efficient optical engine. Also, combining with the D-ILA device that features a narrow gap between pixels for optimum use of light, a powerful yet finely detailed and smooth image projection can be achieved.
*2:Achieved on the DLA NX9. 1,900 lm for the DLA N7 and 1,800 lm for the JVC DLA N5
Realising Images Full of Presence with D-ILA’s High Contrast
JVC’s original D-ILA device combined with an optical engine equipped with a wire grid results in a high native contrast ratio of 100,000:1*3. Input signals are analysed with an original algorithm that is combined with Intelligent Lens Aperture, which automatically controls the black level of the image to achieve a dynamic contrast ratio of 1,000,000:1*3. The synergetic effect based on the dynamic range stemming from high-brightness, delivers sensational 4K video full of reality.
*3:Figures for the DLA NX9. The DLA N7 offers 80,000:1 native contrast ratio and 800,000:1 dynamic contrast ratio; the JVC DLA N5 offers 40,000:1 native contrast ratio and 400,000:1 dynamic contrast ratio.
JVC DLA N5 has support for HDR (High Dynamic Range)
HDR (high dynamic range) content contains more data including an extended brightness range, 10-bit gradation and a wide BT.2020 colour gamut. For this reason, high basic performance is required for precise reproduction by the projector. With D-ILA projectors, HDR content are optimally reproduced with “high-brightness, high contrast, and wide gamut” to enjoy high quality HDR content as you’ve never experienced in the past. Moreover, in addition to HDR10 content, which is found on UHD Blu-ray Discs, the projector automatically detects the Hybrid Log-Gamma (HLG) signal, a technology used widely in broadcasting, allowing the user to view in an optimum picture mode.
The JVC DLA N5 is equipped with new 0.69-in 4K D-ILA devices
Newly developed digital driver LSI for native 4K device
The JVC DLA N5 features an all new 65 mm-diameter high-resolution all-glass lens
1,800 lm Light Output
40,000:1 Native Contrast Ratio
400,000:1 Dynamic Contrast Ratio
Supports High Dynamic Range (HDR10,HLG) content
Available in 2 colours: White and black
